The ASME B16.11 Stainless 2000# Threaded Reducing Tee is a forged fitting used to create a smaller branch line from a larger main run. Forged from grades like 316L or 316Ti, it provides exceptional corrosion resistance and high-pressure integrity. Featuring precision NPT or BSP threads, it enables secure, weld-free reductions. Rated for 2000 PSI, it is a space-saving, hygienic solution for chemical, pharmaceutical, and offshore systems where reliable flow distribution is critical.
Technical Attributes: SS 2000# Threaded Reducing Tee
Standard,ASME B16.11 / BS 3799
Material Grades,"ASTM A182 F304/L, F316/L, F316Ti, F321"
Fitting Type,Reducing Tee (Unequal Outlets)
Pressure Class,2000 LBS (Class 2000)
Size Range,"1/4""×1/4""×1/8"" to 4""×4""×3"""
Thread Type (NPT),ASME B1.20.1 (Tapered)
Thread Type (BSP),BS 21 / ISO 7-1 (Tapered or Parallel)
Manufacturing,"Forged, Solution Annealed, Machined"
Chromium Content,16.0%–20.0%
Nickel Content,8.0%–14.0%
Molybdenum (316L),2.0%–3.0%
Titanium (316Ti),Stabilized against sensitization
Tensile Strength,≥485 MPa (70 ksi)
Yield Strength,≥170–205 MPa
Heat Treatment,Solution Annealing & Water Quench
Testing Standard,"PMI, PT (Liquid Penetrant), Thread Gauging"
Hardness,≤192 HBW
Surface Finish,Pickled and Passivated
Certification,EN 10204 3.1 / MTR
Primary Use,Corrosive Media Branching & Reduction
