The ASME B16.11 Stainless Steel 2000# Threaded Tee is a precision-forged branching fitting for corrosive, medium-pressure systems. Available in grades like 316L or 316Ti, it provides excellent resistance to oxidation and pitting. Featuring NPT or BSP threads, it allows for reliable, weld-free 90-degree intersections. Rated for 2000 PSI, it is a compact and hygienic solution for pharmaceutical, chemical, and food processing lines where ease of assembly and high material purity are mandatory.
Technical Attributes: SS 2000# Threaded Tee
Standard,ASME B16.11 / BS 3799
Material Grades,"ASTM A182 F304/L, F316/L, F316Ti, F321"
Fitting Type,Straight Tee (Equal Tee)
Pressure Class,2000 LBS (Class 2000)
Size Range,1/8" to 4"" (NPS)
Thread Type (NPT),ASME B1.20.1 (Tapered)
Thread Type (BSP),BS 21 / ISO 7-1 (Tapered or Parallel)
Manufacturing,"Forged, Solution Annealed, Machined"
Chromium Content,16.0%–20.0%
Nickel Content,8.0%–14.0%
Molybdenum (316L),2.0%–3.0%
Titanium (316Ti),Stabilized against sensitization
Tensile Strength,≥485 MPa (70 ksi)
Yield Strength,≥170–205 MPa
Heat Treatment,Solution Annealing & Water Quench
Testing Standard,"PMI, PT (Liquid Penetrant), Thread Gauging"
Hardness,≤192 HBW
Surface Finish,Pickled and Passivated
Certification,EN 10204 3.1 / MTR
Primary Use,"Sanitary, Marine, & Chemical Processing"
