The ASME B16.11 Stainless 2000# Threaded Couplings are high-pressure fittings used to join or extend pipes. Full Couplings connect two pipes, while Half Couplings are used for branching or vessel nozzles. Forged from grades like 316L or 316Ti, they offer superior corrosion resistance and high-pressure integrity. Featuring precision NPT or BSP threads, they enable secure, weld-free assembly. Rated for 2000 PSI, these are essential for chemical, offshore, and pharmaceutical systems.
Technical Attributes: SS 2000# Threaded Couplings
Standard,ASME B16.11 / BS 3799
Material Grades,"ASTM A182 F304/L, F316/L, F316Ti, F321"
Fitting Type,Full Coupling / Half Coupling
Pressure Class,2000 LBS (Class 2000)
Size Range,1/8" to 4" (NPS)
Thread Type (NPT),ASME B1.20.1 (Tapered)
Thread Type (BSP),BS 21 / ISO 7-1 (Tapered or Parallel)
Manufacturing,"Forged, Solution Annealed, Machined"
Chromium Content,16.0%–20.0%
Nickel Content,8.0%–14.0%
Molybdenum (316L),2.0%–3.0%
Titanium (316Ti),Stabilized against sensitization
Tensile Strength,≥485 MPa (70 ksi)
Yield Strength,≥170–205 MPa
Heat Treatment,Solution Annealing & Water Quench
Testing Standard,"PMI, PT (Liquid Penetrant), Thread Gauging"
Hardness,≤192 HBW
Surface Finish,Pickled and Passivated
Certification,EN 10204 3.1 / MTR
Primary Use,High-Pressure Instrumentation & Pipe Joining
