The ASME B16.11 Stainless Weldolet is a premium self-reinforcing branch fitting for 90-degree outlets. Forged from grades like 316L or 316Ti, it ensures maximum corrosion resistance and structural integrity across various wall schedules (STD to XXS). It provides a full-penetration butt-weld connection, minimizing stress concentrations in high-pressure headers. Ideal for chemical, marine, and food processing, it eliminates the need for reinforcement pads while maintaining high flow efficiency.
Technical Attributes: SS Forged Weldolet
Standard,MSS SP-97 / ASME B16.11
Material Grades,"ASTM A182 F304/L, F316/L, F316Ti, F321"
Connection Type,Butt-Weld Branch Outlet
Wall Thickness,"STD, XS, SCH 80, SCH 160, XXS"
Run Pipe Size,1/2" to 60" (NPS)
Branch Size,1/4" to 24" (NPS)
Manufacturing,"Forged, Solution Annealed, Machined"
Chromium Content,16.0%–20.0%
Nickel Content,8.0%–14.0%
Molybdenum (316L),2.0%–3.0%
Titanium (316Ti),Stabilized for high-temp service
Tensile Strength,≥485 MPa (70 ksi)
Yield Strength,≥170–205 MPa
Heat Treatment,Solution Annealing & Water Quench
Testing Standard,"PMI, PT (Liquid Penetrant), UT"
Hardness,≤192 HBW
Surface Finish,Pickled and Passivated
Reinforcement,Integrated Self-Reinforcing Design
Certification,EN 10204 3.1 / MTR
