The ASME B16.11 Alloy Steel 2000# Threaded Union is a high-performance three-piece fitting designed for high-temperature, medium-pressure piping. Forged from Chrome-Moly grades like F11 or F22, it ensures exceptional creep resistance and thermal stability. Featuring BSP or BSPT threads and a precision metal-to-metal ground joint, it allows for easy disassembly of steam and refinery lines. Rated for 2000 PSI, it is the industry standard for maintainable joints in extreme thermal environments.
Technical Attributes: Alloy Steel 2000# Threaded Union
Standard,ASME B16.11 / MSS SP-83
Material Grades,"ASTM A182 F5, F9, F11, F22, F91"
Fitting Type,Threaded Union (3-Piece Design)
Pressure Class,2000 LBS (Class 2000)
Size Range,1/8" to 3" (NPS)
Thread Type (BSPT),BS 21 / ISO 7-1 (Tapered)
Thread Type (BSP),BS 2779 / ISO 228-1 (Parallel)
Seal Design,Ground Joint (Conical or Spherical)
Manufacturing,"Forged, Heat Treated, Machined"
Chromium Content,1.0%–9.5% (Grade dependent)
Molybdenum Content,0.5%–1.1% (Grade dependent)
Tensile Strength,≥415–585 MPa
Yield Strength,≥205–415 MPa
Heat Treatment,Normalizing & Tempering / Annealing
Hardness,≤143–248 HBW
Testing Standard,"PMI, UT, Thread Gauging, Hardness"
Surface Finish,Anti-rust Oil / Black Phosphated
Certification,EN 10204 3.1 / MTR
Marking,"Grade, Rating, Size, Thread, Heat No"
Primary Use,High-Temp Steam & Refinery Maintenance
