The Cast Steel WCB DN100 PN16 Lug End Knife Gate Valve is a rugged isolation valve designed for medium-pressure industrial slurries and wastewater. Its WCB carbon steel body offers higher pressure-temperature resilience than iron, while the Lug End design allows for independent downstream piping removal (dead-end service). Featuring a sharp SS304 gate, it easily shears through suspended solids and thick fluids, ensuring a reliable seal in mining, paper pulp, and chemical processing.
Technical Attributes: DN100 PN16 WCB Lug Knife Gate Valve
Body Material,ASTM A216 WCB (Cast Carbon Steel)
Nominal Size,"DN100 (4"")"
Pressure Rating,PN16 (1.6 MPa)
End Connection,Lug Type (Full Lugged)
Flange Drilling,EN 1092-1 / DIN 2501 PN16
Gate Material,AISI 304 Stainless Steel (Polished)
Seat Material,EPDM / NBR (Resilient) or Metal-to-Metal
Sealing Type,Unidirectional (Bidirectional Optional)
Operation,Manual Handwheel
Stem Design,Rising Stem (OS&Y)
Stem Material,ASTM A182 F6a / SS304
Packing Material,PTFE / Braided Graphite
Design Standard,MSS SP-81 / JB/T 8691
Face-to-Face,MSS SP-81 / DIN 3202-K1
Body Coating,Epoxy Resin (Anti-corrosive)
Temperature Range,−29℃ to +120℃ (Resilient Seat)
Testing Standard,API 598 / MSS SP-81
Service Media,"Slurry, Pulp, Sewage, Bulk Solids"
Bolting Material,Zinc Plated Carbon Steel / SS304
