The Aluminium Body PN16 Wafer Butterfly Valve is a lightweight, corrosion-resistant solution for flow control. The aluminum alloy body significantly reduces weight compared to cast iron, making it ideal for plastic piping or weight-sensitive installations. It features a Grade 304 Stainless Steel disc for durability and a PTFE seat for superior chemical resistance and low friction. Rated for PN16, it is commonly used in water treatment, HVAC, and chemical processing.
Technical Attributes: Aluminium Body PN16 Butterfly Valve
Body Material,Aluminium Alloy (Lightweight)
Valve Type,Concentric Wafer Type
Pressure Rating,PN16 (1.6 MPa)
Disc Material,ASTM A351-CF8 (304 Stainless Steel)
Seat Material,PTFE (Teflon)
Stem Material,SS410 / SS416 / SS304
Nominal Diameter,DN40 - DN600 (1.5" - 24")
Applicable Standard,EN 593 / API 609
Face-to-Face Dim,EN 558 Series 20 / ISO 5752
Top Flange Pad,ISO 5211 (For Actuation)
Connection Style,Wafer (Fits between PN10/PN16/ANSI150)
Temperature Range,−20℃ to +120℃ (Seat limited)
Media Type,"Water, Corrosive Chemicals, Food/Beverage"
Operation,"Lever, Gearbox, Pneumatic, or Electric"
Shaft Design,Square or Double-D (Anti-Blowout)
Coating,Epoxy Powder Coated or Anodized
Leakage Class,Class VI (Bubble Tight)
Testing Standard,API 598 / EN 12266
Bushings,PTFE or Bronze
Bolting Material,Stainless Steel or Zinc Plated Steel
