The API 6D A105 Fully Welded Ball Valve (DN1200) is a high-capacity pipeline valve designed for natural gas and oil transmission. Its fully welded body eliminates potential leak paths through bolted joints, ensuring maximum structural integrity for underground or subsea burial. Built from A105 forged steel, this DN1200 (48") valve features a trunnion-mounted ball for manageable torque and Double Block and Bleed (DBB) capability to ensure safe, bubble-tight isolation in critical grids.
Technical Attribute Table: API 6D A105 Fully Welded Ball Valve
1,Design Standard,API 6D / ASME B16.34
2,Body Construction,Fully Welded (No Bolted Flanges)
3,Body Material,Forged Steel ASTM A105 / A350 LF2
4,Nominal Diameter,DN1200 (48 Inch)
5,Pressure Class,"ASME Class 150, 300, 600, 900"
6,Ball Type,Trunnion Mounted (Fixed Ball)
7,Bore Type,Full Bore (Pigging Capable)
8,Seat Type,Spring-Loaded / Self-Relieving
9,Sealing Feature,Double Block and Bleed (DBB)
10,End Connection,Butt-Weld (BW) / Flanged (ASME B16.5)
11,Stem Design,Blow-out Proof / Anti-Static
12,Secondary Seal,Emergency Sealant Injection (Stem/Seat)
13,Fire Safe Design,API 607 / API 6FA Certified
14,Operation,Heavy Duty Gearbox / Buried Actuator
15,Stem Extension,Optional (For Underground/Buried Service)
16,Temperature Range,−29℃ to +120℃ (Standard)
17,Shell Test Pressure,1.5× Rated Pressure
18,Seat Test Pressure,1.1× Rated Pressure (High/Low)
19,Coating,Fusion Bonded Epoxy (FBE) for Burial
20,Transition Pups,Optional (Welded at factory)
