A352 LCC flanged globe valve, Class 300. Features bellows seal for zero leakage and Hastelloy B trim for superior acid resistance. Ideal for low-temperature, hazardous, and corrosive media.
### **Technical Attributes**
| Attribute | Specification |
| --- | --- |
| **Body Material** | ASTM A352 LCC (Low Carbon Steel) |
| **Valve Type** | Globe Valve (Bellows Sealed) |
| **Pressure Class** | ASME Class 300 (PN50) |
| **End Connection** | Flanged (RF - Raised Face) |
| **Trim Material** | Hastelloy B (HAST B) |
| **Bellows Material** | Inconel 625 or SS316L |
| **Design Standard** | BS 1873 / API 623 |
| **Face to Face** | ASME B16.10 |
| **Flange Standard** | ASME B16.5 |
| **Testing Standard** | API 598 |
| **Service Temp** | -46°C to +345°C |
| **Stem Type** | Rising Stem (OS&Y) |
| **Bonnet Type** | Bolted Bonnet / Bellows Housing |
| **Operation** | Handwheel / Gear Operated |
| **Seating Type** | Metal-to-Metal (Hard Faced) |
| **Flow Direction** | Unidirectional (Under Disc) |
| **Media Application** | Corrosive Acids / Toxic Chemicals |
| **Leakage Class** | MSS SP-117 / API 598 Zero Leakage |
