The ASTM A351 CF8 swing check valve is a robust industrial solution designed to prevent backflow in high-pressure piping systems. Made from cast 304 stainless steel, it offers excellent corrosion resistance and durability for water, oil, and gas applications. The Class 300 rating ensures performance under significant thermal and mechanical stress.
Technical Attributes
Body Material,ASTM A351 Grade CF8 (SS304)
Pressure Class,ASME Class 300
End Connection,Flanged (RF/RTJ)
Design Std,API 594 / BS 1868
Face to Face,ASME B16.10
Flange Std,ASME B16.5
Testing Std,API 598
Disc Type,Swing Type
Seat Material,Integral or Renewable SS304
Bolted Cover,Facilitates easy maintenance
Temp Range,-29°C to 425°C
Media,"Water, Steam, Oil, Corrosives"
