The 3-piece forged steel A105 ball valve is a heavy-duty valve designed for high-pressure and high-temperature service. Forged ASTM A105 carbon steel provides superior strength and grain structure compared to cast alternatives, making it ideal for steam, oil, and gas. The 3-piece design allows for easy center-section removal for maintenance. With threaded (NPT) ends, it offers a high-integrity connection for industrial pipelines requiring maximum durability.
Technical Attributes
1,Body Material,ASTM A105 (Forged Carbon Steel)
2,Body Design,3-Piece (Bolted construction for easy repair)
3,Pressure Rating,Class 800 / 2000 PSI / 3000 PSI
4,Size Range,1/4" to 2" (DN8 to DN50)
5,End Connection,NPT Threaded (ASME B1.20.1)
6,Bore Design,Full Bore or Reduced Bore options
7,Ball Material,Stainless Steel (SS304 / SS316)
8,Seat Material,Reinforced PTFE (RPTFE) / PEEK / Delrin
9,Stem Design,Blow-out Proof with Anti-static device
10,External Finish,Black Phosphated or Zinc Plated (Corrosion protection)
11,Testing Standard,API 598 / EN 12266-1
12,Working Temp.,−29∘C to +250∘C (Depending on seat)
