The Top-Entry Ball Valve PN16 is a high-integrity industrial valve designed for in-line maintenance. Featuring a GP240GH (1.0619) cast steel body, it allows internal components to be replaced without removing the valve from the pipeline. Built to EN 1983 standards, it offers a reliable B1 flange finish and a "full bore" design for minimal pressure drop. It is the preferred choice for oil, gas, and chemical processes where downtime must be minimized and leak-proof isolation is mandatory.
Technical Attributes: Top Entry Ball Valve
Standard,EN 1983 / ISO 17292
Nominal Pressure,PN16 (1.6 MPa)
Body Material,GP240GH (1.0619 Cast Carbon Steel)
Construction,Top Entry (One-Piece Body)
Flange Type,EN 1092-1 Type B1 (Raised Face)
Face-to-Face,EN 558 Series 1 / Series 12
Ball Material,1.4408 (SS316) / Chrome Plated Steel
Seat Material,RPTFE / PEEK / Metal-to-Metal
Bore Design,Full Bore (Low Pressure Drop)
Stem Design,Anti-Blowout / Anti-Static Device
Seal Type,Bubble Tight (EN 12266-1 Rate A)
Operation,"Lever, Worm Gear, or Actuator"
Fire Safety,API 607 / ISO 10497 Certified
Temp Range,−29℃ to +200℃ (Soft Seat)
Wall Thickness,EN 12516-1
Testing,Shell: 2.4 MPa; Seat: 1.76 MPa
Certification,CE / PED / EN 10204 3.1
Primary Use,High-Availability Process Maintenance
