Stainless steel CF8M flanged T-strainer PN16 is a filtration device designed to remove solid debris from fluid systems, protecting downstream equipment such as pumps, valves, and meters. The CF8M material (cast equivalent of AISI 316) offers exceptional corrosion resistance for aggressive and marine environments . Its T-strainer configuration features a blow-off connection at the bottom of the strainer body, allowing convenient debris removal without dismantling the pipeline . The flanged ends comply with PN16 (16 bar / 232 psi) pressure rating, ensuring secure, leak-proof connections . Manufactured to EN 1092-1 flange standards and tested per EN 12266-1, these strainers are widely used in chemical processing, water treatment, petrochemical, food and beverage, and HVAC applications .
Technical Attributes & Specifications
1. **Body Material:** ASTM A351 CF8M (Cast 316 Stainless Steel).
2. **Pressure Rating:** PN16 (1.6 MPa / 16 Bar).
3. **Filter Element:** Removable Stainless Steel 316 mesh screen.
4. **Connection Type:** Flanged ends according to EN 1092-1 Type B1.
5. **Design Standard:** ASME B16.34 or EN 12516.
6. **Face-to-Face:** Manufacturer standard or DIN 3202 equivalent.
7. **Screen Mesh:** Ranging from 20 mesh to 400 mesh (Standard 40 mesh).
8. **Cover Design:** Bolted cover with optional quick-release davit arm.
9. **Drain/Blow-off:** Integrated NPT or flanged drain plug for easy flushing.
10. **Flow Configuration:** Straight-through design for minimal pressure loss.
11. **Gasket Material:** PTFE or Reinforced Graphite for chemical inertness.
12. **Internal Volume:** Larger dirt-holding capacity compared to Y-strainers.
13. **Installation:** Suitable for horizontal or vertical pipelines.
14. **Corrosion Resistance:** High resistance to chlorides and organic acids.
15. **Service Temperature:** -196°C to +400°C (depending on seal material).
16. **Maintenance:** Top-entry design allows for in-line screen replacement.
17. **Casting Quality:** Investment casting for smooth internal and external finishes.
18. **Testing Standards:** Shell and leak testing per EN 12266-1 or API 598.
19. **Finish:** Acid-passivated for enhanced oxidation protection.
20. **Applications:** Desalination, chemical reactors, and high-flow water systems.
