The Flanged Lift Type Straight Strainer is a high-performance filtration component designed for industrial piping systems. It utilizes a vertical lift mechanism to house a removable stainless-steel screen, effectively capturing debris while maintaining a streamlined flow path. The straight-through configuration minimizes pressure drops, making it ideal for protecting sensitive downstream equipment like pumps, meters, and valves from particulate damage in liquid or steam service.
Attribute,Specification
Body Material,Cast Steel / Stainless Steel / Ductile Iron
Connection Type,Raised Face Flanged (RF)
Flange Standard,ASME B16.5 / DIN / JIS
Nominal Diameter,"DN50 – DN600 (2"" – 24"")"
Pressure Rating,Class 150 – 600 / PN16 – PN64
Screen Material,SS304 / SS316 / Monel
Mesh Size,20 – 200 Mesh (Customizable)
Seal Type,Bolted Cover with Gasket
Gasket Material,Graphite + SS304 / PTFE
Flow Direction,Uni-directional (Marked on Body)
Design Standard,ASME B16.34
Face-to-Face Dim.,ASME B16.10,DIN3202 F1;
Working Temperature,-29°C to 425°C (Material Dependent)
Applicable Media,"Water, Oil, Gas, Steam"
Installation Position,Horizontal Pipelines
Coating,Epoxy Powder / Heat Resistant Paint
Bolting Material,ASTM A193 B7 / A194 2H
Drain Plug,Included for easy cleaning
WIITH CERTYFICATE: EN10204-3.1
