The Cryogenic Stainless Steel Globe Valve is a specialized solution for extreme low-temperature fluids like LNG ( -162℃) and LN2 ( -196℃). It features an extended bonnet (gas column) to isolate the stem packing from the liquid phase, preventing ice formation. The Butt Welding (BW) ends ensure a permanent, leak-proof joint, vital for high-integrity cryogenic skids. Constructed from Stainless Steel (CF8/CF8M), it maintains high ductility and toughness at absolute zero temperatures.
Technical Attributes: Cryogenic Stainless Steel Globe Valve
Body Material,ASTM A351-CF8 / CF8M (Stainless Steel)
Service Media,"LNG, LN2, LO2, LAR, LHe"
Temperature Range,−196℃ to +80℃
Pressure Rating,Class 150 / 300 / 600 / PN16 - PN100
Bonnet Design,Extended Long Column (Gas Column Type)
End Connection,Butt Welding (BW) to ASME B16.25
Seating Design,Soft Seat (PCTFE/Kel-F) or Metal-to-Metal
Stem Material,ASTM A182-F304 / F316
Design Standard,BS 6364 / ASME B16.34
Face-to-Face,ASME B16.10 / Manufacturer Standard
Packing Material,Low-Temperature V-PTFE / Graphite
Safety Feature,Pressure Relief Hole (to prevent cavity overpressure)
Cleaning,Degreased for Oxygen Service (LO2)
Body Gasket,PTFE / SS304 + Graphite Spiral Wound
Testing Standard,BS 6364 Cryogenic Test / API 598
Operation,Extended Manual Handwheel / Actuator
Size Range,DN15 - DN300 (1/2" to 12")
Body Treatment,Pickled and Passivated
Stem Type,OS&Y (Outside Screw & Yoke)
Certification,Fire Safe / PED 2014/68/EU
