A Wafer Centric Butterfly Valve for Natural Gas is a specialized quarter-turn valve designed for the safe isolation and regulation of gas flow in low to medium-pressure pipelines. Unlike standard water valves, these are engineered with specific materials and certifications (such as EN 161, DVGW, or API 607) to handle the volatile and dry nature of fuel gases like natural gas, methane, and LPG.
The "Wafer" design allows the valve to be sandwiched between two pipe flanges, making it incredibly compact and cost-effective
Technical Attributes
1,Design Standard,EN 12334 / MSS SP-136 / API 6D
2,Size Range,DN150 to DN2000 (6" to 80")
3,Body Material,Ductile Iron (GGG40 / GGG50 / ASTM A536)
4,Disc Material,Ductile Iron (Aerodynamic profile)
5,Pressure Class,PN10 / PN16 / PN25 / Class 150
6,Sealing Design,Double Eccentric / Tilting Seat
7,Seat Material,Stainless Steel (SS304/316) or Bronze
8,Disc Ring Material,EPDM / NBR (Resilient) or Stainless Steel (Metal)
9,Face-to-Face Dim.,EN 558 Series 14 (DIN 3202 F4)
10,Shaft / Pivot Pin,Stainless Steel (2Cr13 / SS304 / SS316)
11,Bearing / Bushing,Self-lubricating Bronze or PTFE coated
12,Connection Type,Double Flanged
13,Flange Standard,EN 1092-2 / ASME B16.1 / B16.42
14,Coating,"Fusion Bonded Epoxy (FBE), Blue RAL 5005"
15,Coating Thickness,≥ 250 Microns
16,Optional Accessory,Hydraulic Damper / Counterweight (Lever & Weight)
17,Mounting Position,Horizontal (Preferred) or Vertical (Upward flow)
18,Tightness Class,EN 12266-1 Rate A (Soft) / Rate C (Metal)
19,Working Temp.,−10°C to +80°C (Standard)
20,Applicable Media,"Potable Water, Raw Water, Cooling Water"
