The A350 Gr.LF2 150LBS Globe Valve is a low-temperature service valve designed for reliable shut-off and throttling in cryogenic and cold-environment applications. The body is forged from A350 Gr.LF2—a carbon steel grade specifically heat-treated for impact resistance at sub-zero temperatures down to -46°C (-50°F). Rated for 150LBS (Class 150), it is suitable for moderate-pressure systems in petrochemical plants, LNG terminals, refrigeration systems, and offshore platforms. The globe valve design offers precise flow control with a linear flow characteristic. Its forged construction ensures structural integrity, while optional bonnet extensions can accommodate cold-box insulation requirements. This valve combines durability, safety, and performance in demanding low-temperature environments.
Technical Attributes & Specifications
1. **Body Material:** ASTM A350 Grade LF2 (Low-temp Carbon Steel).
2. **Pressure Class:** ASME Class 150 (150LBS).
3. **Service Temperature:** Rated for environments down to **-46°C (-50°F)**.
4. **Design Standard:** API 623, BS 1873, or ASME B16.34.
5. **Connection Type:** Flanged (Raised Face or Flat Face per ASME B16.5).
6. **Face-to-Face:** Compliant with ASME B16.10 standards.
7. **Trim Material:** Standard API Trim #8 (Stellite/13Cr) or Trim #5 for high durability.
8. **Sealing:** Metal-to-metal seating for long-term wear resistance.
9. **Stem Type:** Outside Screw and Yoke (OS&Y) with rising stem.
10. **Bonnet Design:** Bolted bonnet with high-integrity spiral wound gasket.
11. **Stem Packing:** Die-formed flexible graphite for low-emission sealing.
12. **Operation:** Manual handwheel; adaptable for electric or pneumatic actuators.
13. **Impact Testing:** Mandatory Charpy V-Notch testing per ASTM A350.
14. **Flow Characteristic:** Linear flow control for precise throttling.
15. **Disc Type:** Swivel plug disc or parabolic disc for fine regulation.
16. **NDT Testing:** Visual, Dimensional, and Hydrostatic testing per API 598.
17. **Corrosion Protection:** Exterior coated with low-temp resistant epoxy paint.
18. **Seat Ring:** Renewable threaded or seal-welded seat rings.
19. **Backseat Feature:** Integral backseat allows packing replacement under pressure.
20. **Applications:** Cold-climate oil pipelines, LNG terminals, and LPG storage.
